USS Arleigh Burke Ship Models
(this will be the best plastic model of the ship)
List price $89.95 kit#  DC034- 18" long. our price $65.95


Great Gift Package. Click here for info!

Painted 1/350 scale Modern Sailors

 If you have never super detailed a ship before this kit comes with free photoetching. Try this kit you'll love building this one.

Essential Skills Scale Modeling


Were you a teenager the last time
you built a model?


A step-by-step introduction to scale modeling basics.
Beginning scale modelers are full of questions:
What kinds of models are there? What kinds of tools
do I need? What glue works best?
How do I put a model together?
How are the decals applied?
Finally, Kalmbach offers answers to
all these beginner questions and more.

This new book is filled with more pictures
and how to articles than their other book.


List $21.95  Our Price BK01 19.95


USS Arleigh Burke Class Aegis Naval Ship Models

Destroyers - DDG

Description
These fast warships provide multi-mission offensive and defensive capabilities, and can operate independently or as part of carrier battle groups, surface action groups, amphibious ready groups, and underway replenishment groups.

Features
Guided missile destroyers are multi-mission [Anti-Air Warfare (AAW), Anti-Submarine Warfare (ASW), and Anti-Surface Warfare (ASUW)] surface combatants. The addition of the Mk-41 Vertical Launch System (VLS) to the destroyer armament has greatly expanded the role of the destroyer in strike warfare.

Background
Technological advances have improved the capability of modern destroyers culminating in the Arleigh Burke (DDG 51) class replacing the older Charles F. Adams and Farragut-class guided missile destroyers. Named for the Navy's most famous destroyer squadron combat commander and three-time Chief of Naval Operations, the USS ARLEIGH BURKE was commissioned July 4, 1991, and was the most powerful surface combatant ever put to sea. Like the larger Ticonderoga-class cruisers, DDG 51's combat capability centers around the Aegis Weapon System (AWS). AWS is composed of the SPY-1D multi-function phased array radar, advanced AAW and ASW systems, VLS, and the Tomahawk Weapon System. These advances allow the Arleigh Burke-class to continue the revolution at sea.

The Arleigh Burke-class employs all-steel construction and is comprised of three separate variants or “flights”; DDG 51-71 represent the original design and are designated Flight I ships, DDG 72-78 are Flight II ships, DDG 79 and Follow ships are built to the Flight IIA design.

Like most modern U.S. surface combatants, DDG 51 utilizes gas turbine propulsion. Employing four General Electric LM 2500 gas turbines to produce 100,000 total shaft horsepower via a dual shaft design, Arleigh Burke-class destroyers are capable of achieving 30 plus knot speeds in open seas.

The Flight IIA design includes the addition of the Kingfisher mine-avoidance capability, a pair of helicopter hangars which provide the ability to deploy with two organic LAMPS Mk III MH-60 helicopters, blast-hardened bulkheads, distributed electrical system and advanced networked systems. Additionally, DDG 91-96 provide accommodations for the A/N WLD-1 Remote Mine-hunting System. The first Flight IIA, USS OSCAR AUSTIN, was commissioned in August 2000.

A DDG Modernization Program is underway to provide a comprehensive mid-life upgrade that will ensure the DDG 51 class will maintain mission relevance and remain an integral part of the Navy’s Sea Power 21 Plan. The goal of the DDG Modernization effort is to reduce manning requirements and increase war fighting capabilities while reducing total ownership cost to the Navy. The DDG Modernization technologies will be integrated during new construction of DDG 111 and 112, then retrofitted into DDG Flight I and II ships during in service overhaul periods.

Point Of Contact
Public Affairs Office
Naval Sea Systems Command (OOD)
Washington, DC 20362

General Characteristics, Arleigh Burke class

Builder: Bath Iron Works, Northrop Grumman Ship Systems.
SPY-1 Radar and Combat System Integrator: Lockheed Martin
Date Deployed: July 4, 1991 (USS Arleigh Burke)
Propulsion: Four General Electric LM 2500-30 gas turbines; two shafts, 100,000 total shaft horsepower.
Length: Flights I and II (DDG 51-78): 505 feet (153.92 meters)
Flight IIA (DDG 79 AF): 509˝ feet (155.29 meters).
Beam: 59 feet (18 meters).
Displacement: DDG 51 through 71: 8,230 L tons (8,362.06 metric tons) full load DDG 72 through 78: 8,637 L tons (8,775.6 metric tons) full load DDG 79 and Follow: 9,496 L tons (9,648.40 metric tons) full load.
Speed: In excess of 30 knots.
Crew: DDG 79-84; 278 (24 officers); DDG 85-102 276 (24 officers)
Armament: Standard Missile (SM-2MR); Vertical Launch ASROC (VLA) missiles; Tomahawk®; six Mk-46 torpedoes (from two triple tube mounts); Evolved Sea Sparrow Missile (ESSM) (DDG 79 AF)
Aircraft: Two LAMPS Mk III MH-60 B/R helicopters with Penguin/Hellfire missiles and Mk 46/Mk 50 torpedoes.
Ships:
USS ARLEIGH BURKE (DDG 51), Norfolk, VA
USS BARRY (DDG 52), Norfolk, VA
USS JOHN PAUL JONES (DDG 53), San Diego, CA
USS CURTIS WILBUR (DDG 54), Yokosuka, Japan
USS STOUT (DDG 55), Norfolk, VA
USS JOHN S. McCAIN (DDG 56), Yokosuka, Japan
USS MITSCHER (DDG 57), Norfolk, VA
USS LABOON (DDG 58), Norfolk, VA
USS RUSSELL (DDG 59), Pearl Harbor, HI
USS PAUL HAMILTON (DDG 60), Pearl Harbor, HI
USS RAMAGE (DDG 61), Norfolk, VA
USS FITZGERALD (DDG 62), Yokosuka, Japan
USS STETHEM (DDG 63), Yokosuka, Japan
USS CARNEY (DDG 64), Mayport, FL
USS BENFOLD (DDG 65), San Diego, CA
USS GONZALEZ (DDG 66), Norfolk, VA
USS COLE (DDG 67), Norfolk, VA
USS THE SULLIVANS (DDG 68), Mayport, FL
USS MILIUS (DDG 69), San Diego, CA
USS HOPPER (DDG 70), Pearl Harbor, HI
USS ROSS (DDG 71), Norfolk, VA
USS MAHAN (DDG 72), Norfolk, VA
USS DECATUR (DDG 73), San Diego, CA
USS McFAUL (DDG 74), Norfolk, VA
USS DONALD COOK (DDG 75), Norfolk, VA
USS HIGGINS (DDG 76), San Diego, CA
USS O'KANE (DDG 77), Pearl Harbor, HI
USS PORTER (DDG 78), Norfolk, VA
Attention very important at present there is a plastic model that represents the later
Arleigh Burkes FLT IIA with the Hangar on the Fantail click the link below.
Click here to build these ship DDG-79 to 112

USS OSCAR AUSTIN (DDG 79), Norfolk, VA

USS ROOSEVELT (DDG 80), Mayport, FL
USS WINSTON S. CHURCHILL (DDG 81), Norfolk, VA
USS LASSEN (DDG 82), Yokosuka, Japan
USS HOWARD (DDG 83), San Diego, CA
USS BULKELEY (DDG 84), Norfolk, VA
USS McCAMPBELL (DDG 85), San Diego, CA
USS SHOUP (DDG 86), Everett, WA
USS MASON (DDG 87), Norfolk, VA
USS PREBLE (DDG 88), San Diego, CA
USS MUSTIN (DDG 89), San Diego, CA
USS CHAFEE (DDG 90), Pearl Harbor, HI
USS PINKNEY (DDG 91), San Diego, CA
USS MOMSEN (DDG 92), San Diego, CA
USS CHUNG-HOON (DDG 93), San Diego, CA
USS NITZE (DDG 94), Norfolk, VA
USS JAMES E. WILLIAMS (DDG 95), Norfolk, VA
USS BAINBRIDGE (DDG 96), Norfolk, VA
USS HALSEY (DDG 97), San Diego, Calif.
USS FORREST SHERMAN (DDG 98), Norfolk, VA
USS FARRAGUT (DDG 99), Mayport, FL
USS KIDD (DDG 100), San Diego, CA
USS GRIDLEY (DDG 101), San Diego, CA.
PCU SAMPSON (DDG 102), San Diego, CA
PCU TRUXTUN (DDG 103), Norfolk, VA
PCU STERETT (DDG 104), San Diego, CA
PCU DEWEY (DDG 105), San Diego, CA
PCU GRAVELY (DDG 107)
PCU WAYNE E. MEYER (DDG 108 )
(Under Contract) (DDG 112)
